ATEX Approved Coriolis Mass Flow Meter
Sealand is a trustworthy manufacturer of Mass Flow Meter Coriolis, Mass Flowmeter Coriolis, Flow Meter Coriolis and Meter Coriolis, ATEX, CE & IECEx approved.
The flow meter model covers from DN03 to DN150, and bigger models are being developed. Main specification is as follows.
Model No.
Diameter
(mm)
Max. flow rate
(kg/min)
MWP.
(MPa)
Accuracy grade
(%)
Zero stability
(kg/h)
CG-03
03
6
4
0.1/ 0.2/ 0.5
0.012
CG-06
06
18
4
0.1/ 0.2/ 0.5
0.04
CG-15
15
50
25
0.1/ 0.2/ 0.5
0.12
CNG-20
20
120
25
0.1/ 0.2/ 0.5
0.36
CG-25
25
200
4
0.1/ 0.2/ 0.5
0.62
CG-40
40
500
4
0.1/ 0.2/ 0.5
1.60
CG-50
50
1000
4
0.1/ 0.2/ 0.5
2.38
CG-80
80
3000
4
0.1/ 0.2/ 0.5
7.05
CG-100
100
3600
4
0.1/ 0.2/ 0.5
12.00
CG-150
150
8000
4
0.1/ 0.2/ 0.5
50.00
Mass Flow Meter Coriolis, Mass Flowmeter Coriolis, Flow Meter Coriolis, Meter Coriolis Zhejiang Sealand Technology Co., Ltd. , https://www.sealandflowmeter.com
Functional coatings are specialized materials designed to perform beyond basic protection. These coatings offer additional properties that enhance the performance, durability, and functionality of the surfaces they cover. As industries evolve and demand more efficient solutions, functional coatings have become essential in various sectors, from construction to aerospace. Their development is driven by the need for materials that can withstand extreme conditions while delivering added value.
One of the most common types of functional coatings is reflective and heat-insulating energy-saving coatings. These coatings work by reflecting a large portion of solar radiation, particularly in the visible and infrared spectrum, preventing heat buildup on surfaces. They also incorporate insulating components like hollow ceramic microspheres, which create a vacuum layer that blocks heat transfer. Additionally, these coatings can emit absorbed heat as infrared radiation, further improving their cooling effect. With high reflectivity, long-term durability, and eco-friendly formulation, they are ideal for use in buildings, industrial equipment, and vehicles.
Another important type is drag-reducing anti-fouling coatings, commonly used in oil pipelines. These coatings prevent wax buildup by altering the surface properties of the pipe, reducing friction and improving flow efficiency. By minimizing wax adhesion, they help maintain pipeline capacity and reduce energy consumption during transportation. The coating’s chemical stability, wear resistance, and smooth surface make it suitable for harsh environments, offering significant economic benefits.
High-temperature far-infrared ceramic coatings are another key innovation. Designed for industrial kilns and furnaces, these coatings improve thermal efficiency by enhancing radiative heat exchange. Made with advanced inorganic-organic hybrid technology, they offer excellent heat resistance, corrosion protection, and mechanical strength. Their ability to emit infrared radiation effectively helps reduce energy waste and prolong the life of refractory materials.
In summary, functional coatings play a crucial role in modern industry. Whether it's reducing heat, preventing fouling, or improving thermal performance, these materials are continuously evolving to meet the demands of complex applications. As technology advances, we can expect even more innovative solutions that push the boundaries of what coatings can achieve.
Analysis of Main Functional Coatings at Home and Abroad
